AOTM Auto Object Tracking Module For Drone Zoom Camera
Overview
The ATOM auto object tracking module (available in SD and HD versions) delivers real-time tracking of static or moving targets in complex backgrounds from UAVs and other high-speed platforms. It reliably handles image affine transformations caused by rapid motion, as well as target panning, zooming, and rotation. With exceptional real-time processing and extensibility, the ATOM seamlessly integrates drone imaging with intelligent analytics, providing robust support for industrial inspection, disaster response, and environmental monitoring.
High-Quality Materials
Intuitive Interface
The ATOM pairs two precision-engineered circuit boards with premium materials and an intuitive interface, ensuring easy installation and dependable field performance.
Accurate AI Identification
AI-Powered EO/IR Target Detection
Designed for real-time, high-precision target recognition, ATOM-II combines AI algorithms with EO and IR imaging. It delivers reliable automatic detection and classification for efficient aerial operations.
Intelligent Target Tracking
Intelligent EO/IR Target Tracking
Powered by advanced AI algorithms and EO/IR sensors, ATOM enables real-time, high-precision tracking of vehicles and individuals—even during target panning, zooming, rotation, or partial occlusion.
Accurate Tracking Pipeline
Reliable Tracking with Affine & Lighting Adaptation
The ATOM is engineered to adapt robustly to image affine transformations and illumination variations caused by high-speed movement, significantly enhancing the entire tracking pipeline—from initial detection to continuous tracking—while avoiding target loss due to rapid rotation, scale changes, tilting, or partial occlusion.
Flexible Video Input & Storage
HDMI Video Input & TIFF Image Storage
The ATOM works with SD or HD HDMI video sources and TIFF storage, providing hassle-free compatibility across camera setups and uncompressed image quality.
Strong Environmental Adaptability
ATOM Wide Temperature Environmental Adaptability
Exhibiting strong environmental adaptability from -40°C to 60°C, ATOM supports quick startup and continuous operation across diverse operational conditions.
YANGDA object tracking module for drone zoom camera
Auto Object Tracking Module Ground Test
| Video format | Video input | SD video/HD 10801/HD1080P |
| Video output | SD video/HD 10801/HD1080P | |
| Tracking index | Data refresh rate | 50H2/25HZ |
| Output lag | <10ms | |
| Minimum target contrast | 0.05 | |
| Tracking speed | +32pixel/frame | |
| Target effective memory | 100frame | |
| Target size | 16x16 pixels to 160x160 pixels | |
| Environmental suitability | Working temperature | -40°C~60°C |
| Storage temperature | 40°C~65°C | |
| Shake | Meet the GJB 150A vibration test conditions | |
| Strike | Meet the GJB 150A vibration test conditions | |
| Others | Volume | 38mm x 38 mm x 16mm |
| Weight | <30g | |
| Power consumption | <2W |
